Create colorful world
Fluoroethylene vinyl ether(FEVE) resins were developed in Japan in the early 1980’s. It is second-generation fluoropolymer coating with a similar level of durability, weatherability , adhesive force, flexibility, and color and gloss retention as PVDF coatings.
FEVE coating, with polyurethane as base and fluoride polymer as top coating, has good feature of weather resistance of 10 years for exteriors use. Different from PVDF coating, it guarantees fresher,vivid color and higher gloss level, provide more choice for designer. It is available in colors that are not feasible with other coating system.
Soft white or bright red? Solid colours are always a good choice when a uniform appearance without special effects is required.
Fluoroethylene vinyl ether(FEVE) resins were developed in Japan in the early 1980’s. It is second-generation fluoropolymer coating with a similar level of durability, weatherability , adhesive force, flexibility, and color and gloss retention as PVDF coatings. The main differences between these two exterior coating technologies is that PVDF resin based coating has a limitation on the maximum gloss, it can achieve of 20%-40%, FEVE coatings on the other hand, can achieve a wider gloss range f 20%-80%. The primary applications for panels sheets coated with FEVE resins are for architectural and outdoor signage, where high gloss and durability are important. FEVE coatings also offer excellent chalking and corrosion resistance.
*With high glossy and Vivid colors as PE coating
*With high weather resistant as PVDF coating
*High surface hardness ,Pencil hardness is over 4H
*Special for markedness building and Sign industry
| Aluminum alloy | AA1100 AA3003 |
| Aluminum skin | 0.21mm,0.30mm,0.35mm,0.40mm,0.45mm,0.5mm |
| Panel thickness | 3mm,4mm,5mm,6mm |
| Panel width | 1220mm,1250mm,1500mm |
| Panel length | 2440mm,3050mm,4050mm |
| Surface treatment | FEVE |
| Colors | 70 colors, special colors available upon request |
| Customers size | accepted |
| 30%-50% | 20%-80% |
| Description | Test standard | PEVE |
| Thickness of coating | PVDF paint≥25um | 32um to 36um |
| Coating flexibility (T-bend) | Polyester paint≥3T | 3T |
| Color different | ΔE≤2.0(follow color sample) | ΔE<1.0 |
| Pencil hardness | ≥HB | ≥4H |
| Chemical resistance | 5%HCI or 5% NaOH test in 24 hours -No change;ASTM D1308 | No change |
| Coating adhesion | ≧1grade for 10*10mm2 gridding test | 1grade |
| Resist solvent | No change for 200 times(MEK) | No change |
| Boiling water resistance | Coating no tear off for 2 hours | No TEAR OFF |
Peeling strength/ stripping strength | Average ≥7N/mm of 180oc peel off for panel with 0.5mm alu.skin | 7N/mm |
| Impact test for paint | 50KGNaN impact-paint no split for panel | No split |
| Abrasion resistance (L/Mil) | ASTM D968 | 44 |
| Temperature resistance | -40℃ to +80℃ temperature without change of color difference and paint peel off, peeling strength average drop rate ≤10% | Change of glossy only,no paint Peel off |
Coefficient of linear Thermal Expansion | 100℃ temperature difference | 2.4mm/m |
| Detergent resistance (3%) | ASTM D2248 | No change |
Humidity Resistance (3000hrs,100%RH,100°F) | ASTM D2247 | No change |
Salt spray resistance (3000hrs,5% salt) | ASTM B117 | No change |
| Resistance to Staining | 4000h radiate in 800W/m2 in humidity condition, glossiness deviation less grade 2,color difference ≤4.0 | No change |
The company possesses production lines for aluminum-plastic panels whose annual output is 520 million square meters.
